Susceptibility of soil to wind erosion in arid area of the Central Rift Valley of Ethiopia
© Biyensa et al. 2015
Received: 19 March 2015
Accepted: 7 May 2015
Published: 29 May 2015
In Central Rift Valley (CRV) of Ethiopia, renewable land resources are under pressure. Acacia woodland clearance, frequent cultivation, crop residue removal and mono-cropping are among the major land mis-management practices in the area. This has largely been affecting the soil quality. The current study is aimed at assessing the impact of Acacia woodland conversion, and the subsequent mis-managements on selected soil physical properties, and their relation to the prevailing wind erosion in the area. For this study, four land use/land cover types, namely protected woodland (PWL), managed pastureland (MPL), parkland agroforestry (PAF) and treeless cropland (TLCL) were considered.
Higher (P < 0.001) macro-aggregates (>0.25 mm) fraction of soil was found under PWL and MPL while higher fraction of micro-aggregates (0.053–0.25 mm) of soil was found under PAF and TLCL. Soil under PAF and TLCL had higher (P < 0.001) proportion of aggregates of < 1 mm, implying potential susceptibility of the soil to wind erosion. Higher soil bulk density (BD) was found in the most top layer (0–15 cm) of TLCL and PAF, and this could be attributed to the trampling effect by animals freely released to these land use types.
In the study area, conversion of native woodland to PAF and TLCL and the subsequent mismanagements negatively affected some soil physical properties, thereby enhancing severity of soil erosion by wind. In contrast, although not commonly practiced by smallholder farmers, soil under MPL is more stable and less susceptible to wind erosion.
KeywordsAndosols Dry aggregation stability Land degradation Crop residue removal
Soil physical properties could be affected not only by land use changes but also by land management practices (Liu et al. 2006; Snyder et al. 2009; Alberti et al. 2010; Rouw et al. 2010). Soil compaction may occur under cultivated lands due to intensive cropping, short crop rotation, and inappropriate soil management (Quirogaa et al. 1999; Hamza and Anderson, 2005). Bulk Density (BD) is found to be decreased significantly in the order of no - tillage > manual tillage > plough - plough tillage > plough - harrow (Osunbitana et al. 2005).
Another important factor affecting soil physical properties is livestock trampling. Releasing cattle to cultivated land for foraging was reported to cause soil compaction (Hamza and Anderson 2005). This affects associated soil physical properties such as BD, infiltration, and porosity (Siri-Prieto et al. 2007). It significantly increases soil BD and decreases porosity in the upper soil profile (Binkley et al. 2003; Chaichi et al. 2005; Curran-Cournane et al. 2010) and under similar soil type (Martínez and Zinck 2004; Sharrow 2007). The premise behind is that cattle can exert pressure up to 0.2 MPa (Mega Pascal), which is significantly greater than the pressure exerted on the soil surface by tractors, which can vary from 0.03 to 0.15 MPa, and this may lead to soil compaction; which in turn could increase BD (Proffitt et al. 1993). But, the impact is mostly pronounced in the topsoil (Proffitt et al. 1995). This in turn results in loss of pasture production and quality (Hamza and Anderson 2005).
However, there may be variation even among stock types like cow, sheep and goats (Curran-Cournane et al. 2010). In Lar-rangeland, Iran, Chaichi et al. (2005) assessed impact of grazing on soil BD, and reported that it was higher in the upper layer 0–15 cm than in the 15–30 cm. However, to detect such a significant difference in these soil physical properties, the land has to be allowed to grazing for longer period of time. For example, an experiment conducted by Radford et al. (2008) in Central Queensland, on change in soil physical properties after a land had been allowed to grazing for a short period of time did not show any significant difference.
Dry aggregate stability is one of the most important soil physical parameters that are used to estimate erosion susceptibility of soils (Greeves et al., 2007). On the other hand, soil aggregate stability is a function of different soil management factors such as tillage frequency (Masri and Ryan 2006), intensity of grazing (de Souza et al. 2010) and land use change (Gajić et al. 2013). Loss of soil aggregate stability could enhance soil erodibility. Susceptibility to erosion goes higher as aggregate size of soils decrease. The macro-aggregates that are characterized by higher SOC and N (Wilson et al. 2009) are less susceptible to wind erosion than the micro-aggregates (Yang et al. 2007). However, the macro-aggregates are more prone to management impacts (Ashagrie et al. 2007). This implies that poor land management options deteriorates these macro-aggregates, and leads to soil erosion.
Land degradation, a result of land miss-management practice, is commonly observed in Central Rift Valley (CRV) of Ethiopia. Among all, Acacia woodland conversion to different land uses is the most common practice in this area. On the other hand, the Acacia are the main means of livelihood for the rural economy of the area. This is sometimes reflected by the use of these trees for fuel wood, fodder, nitrogen fixation, and shade (Getachew and Ståhl 1998). In spite of its environmental, ecological and socio-economic importance, it has been under pressure (Getachew and Ståhl 1998; Jansen et al. 2007; Yimer and Abdelkadir 2010). Following the conversion, some common land uses, which have been conventionally managed, have evolved.
A few studies have been conducted on the impact of cultivated and grazing lands, without distinguishing between cultivated land with trees and cultivated land without trees, on soil properties. These studies have also not considered the alternative land use option to free grazing, the managed pastureland (MPL). The current study is therefore aimed at evaluating the impact of the two distinct conventional farming systems, the TLCL and the PAF as well as the MPL on BD, porosity, moisture content (MC) and aggregate stability.
Sampling and laboratory analysis
The PWL was used as a reference since the other land uses were formed by converting this land use type. The design was pseudo-completely randomized design with three replications. Per replicate, five 20*20 m random plots were considered. Soil samples were collected at the center and four corners of each plot along the soil depth of 0–15 cm, 15–30 cm, 30–45 cm and 45–60 cm using riverside auger. Hence, a total of 100 samples (5 samples × 5 plots × 4 depths) were collected for each replicate. Then, the 25 samples from each respective depth range were thoroughly mixed, and one composite soil sample weighing 1 kg was taken. A total of 48 (3 replicates × 4 depth range × 4 land use) composite soil samples were taken to the Zeway Soil Testing Laboratory for the analysis of texture, gravimetric moisture content (MC) and porosity (P). Additionally, nine separate core samples were taken from the middle of each of the 20 × 20 m random plots for bulk density (BD) analysis at the depth ranges of 0–15 cm, 15–30 cm, 30–45 cm and 45–60 cm. Then, a total of 540 core samples i.e. (9 sample × 5 plot × 3 rep × 4 land uses) were collected. From each of the 20 × 20 m random plots, a total of 300 i.e. (5 samples × 5 plot × 3 rep × 4 land uses) undisturbed soil samples were collected from the top 0–15 cm depth only for dry aggregate stability test. All the five samples per plot were composited to one sample with little disturbance, and only 60 (5 sample × 3 rep × 4 land use) samples were taken for sieving.
Soil texture was estimated using Hydrometer method. Samples were oven dried at 105 (°C) for 24 h, and BD was calculated as oven dried mass per core volume. Gravimetric moisture content was calculated as the ratio of weight of water to weight of oven dry soil. It is a weight fraction calculated as subtracting weight of oven dried soil from initial fresh sample weight divided by dry weight of the sample. Following the methods described by Hao et al. (2008), for dry aggregate stability estimation, each undisturbed sample was air dried for seven days, and carefully added to nests of sieves, with a pan underneath, having 2 mm, 1 mm, 0.5 mm, 0.25, and 0.053 mm size arranged from top to bottom, respectively, on the shaker apparatus. Each sample was added to the top sieve and subjected to shaking for 30 s (Hao et al. 2008). The remained fraction on each sieve was weighed using sensitive digital balance.
Measurements, calculations and data analysis
Where X stands for sieve size and i is from 1–6 (representing the fraction sizes considered for this study), W xi is weight of soil retained on X i , W sxi is weight of sand fraction on X i , W tss is total soil sample, and W st is sand fraction in total soil sample.
Where, P is total porosity, BD is bulk density and PD is particle density.
Data were subjected to two way Analysis of Variance (ANOVA) using SAS version 9 (SAS Institute 2002). Tukey’s HSD mean separation technique was employed to separate means, where significant difference (p < 0.05) was found between means.
Results and discussion
Soil pH and textural class of the land use and land cover types considered for the study
In this study, the observed similar textural class of soil under the different land uses minimized differences in soil physical and chemical properties that could have been observed due to the difference in soil texture. Therefore, it is more likely that differences in soil physical and chemical properties among the different land uses in the study area could be due to other land use change and land management factors.
Dry aggregate stability
Soil dry aggregate stable size distribution
Macro-aggregate class (>0.25 mm) was higher (P < 0.001) under MPL (73.7 %) and PWL (72.6 %) as compared to PAF and TLCL (Fig. 4). On the other hand, micro-aggregate class (0.053–0.25) was higher under TLCL (35.4 %) followed by PAF (27.6 %). Macro-aggregates are reported to contain higher amount of SOC and N over micro-aggregates (Jiao et al. 2006).
On the other hand, macro-aggregates are more prone to management (Ashagrie et al. 2007) than micro-aggregates which are relatively stable. The result of this study could imply that the higher sensitivity of soil under PWL and MPL to abrupt loss of aggregate stability if they are converted to TLCL and PAF.
Land use type affects soil wind erodiblity by affecting percent DASD. Resistance to wind erosion of soil, has been evaluated towards the percent DASD of ≥ 0.84 mm (Chepil 1952; Lyles and Tatarko 1988; Díaz-Zorita et al. 2002; Greeves et al. 2007), and aggregates less than 0.84 mm are highly susceptible to wind erosion; whereas, those above this range are less susceptible to wind erosion. However, Woodruff and Siddoway (1965) found that soil aggregates < 1 mm are also potentially erodible by wind, of which the micro-aggregates (0.05–0.25 mm) are the most erodible soil fraction (Yang et al., 2007). Therefore, this implies soil under TLCL and PAF is potentially more erodible than soil under PWL and MPL. This could be attributed to the lands under TLCL and PAF have been tilled for more than 25 years continuously, crop residues are removed and mono-cropping is practiced under these land use types. Thus, these might have lost aggregate forming substances such as organic matter (OM).
Intensive grazing (de Souza et al. 2010), absence of tillage (PWL) and periodic tillage (MPL) resulted in lower fraction of soil that are potentially susceptible to wind erosion (Masri and Ryan 2006). The higher organic matter from litter-falls, root death of the Acacia trees and absence of tillage under the PWL enhanced fraction of coarse aggregates. In case of the MPL, however, the result could be attributed to the existence of Rhodes grass straw and the less tillage frequency on the land use (Børresen 1999). This could also be attributable to the existence of high SOC, moisture content and porosity that might have created suitable environment for micro- organisms such as the arbuscular mycorrhizal fungi, which of their hyphae might have created strong binding effect (Hartmann, 2008). Wilson et al. (2009) conducted long term experiment at the Konza Prairie Biological Station, Kansas, and found that there was strong relationship between aggregation stability, SOC and N sequestration, and abundance of arbuscular mycorrhizal fungi.
Geometric mean diameter and mean weight diameter
Bulk density, total porosity and moisture content
In the study area, free grazing is very common, and this might have caused trampling effect, and that might be accounted for the increase in soil BD in the upper soil layer. Animal trampling effect in most cases resulted in high BD (Proffitt et al. 1993, 1995; Chaichi et al. 2005; Bell et al. 2011). Chaichi et al. (2005) found similar result in Lar rangeland of Iran, and reported higher BD in the top 0–15 cm depth than the 15–30 cm. The lowest soil BD was observed in the top 0–15 cm under MPL, when compared to the other three land uses. This could be attributable to pasture under MPL is protected from direct grazing by cattle, and the grass is used in a cut and carry system.
Increase in BD reduces soil quality in such a way that it affects associated soil parameters such as soil infiltration, porosity and moisture content thereby reducing crop productivity at large (Bell et al. 2011). Soil with high BD enhances erosion and limits optimum crop root growth which in turn has negative impact on total plant’s biomass production and yield. Therefore, in order to sustain soil productivity, protecting the land from free grazing and appropriate crop residue management should be taken in to account.
Gravimetric soil moisture content (MC) was significantly higher (P < 0.001) under PWL and MPL than PAF and TLCL (Fig. 7). This may be attributable to the presence of trees and shrub in the PWL, and the presence of straw on the MPL that covers the soil from direct sun-light and which keeps the soil cool (Lal 2004). Børresen (1999) compared different straw managements such as chopping, direct incorporation, burning and removing on soil physical and chemical properties and found that a straw cover maintained soil moisture and increased crop yield during the dry seasons.
The relatively higher MC content in MPL than PWL may be due to the impact of the incorporated Rhodes grass straw and the addition of N and P containing fertilizers to the MPL to enhance biomass production of the Rhodes grass. Zeleke et al. (2004) found that incorporating residue with fertilizer, in CRV of Ethiopia, improved soil properties when compared to application of crop residue alone. The highest soil mean porosity under MPL may be attributed to the relatively lower animal trampling in the MPL. The relatively more porosity of soil under MPL as compared to the PAF and TLCL could be also owing to the contribution of the organic matter added to the soil from Rhodes grass straw and root (Børresen 1999; Singh et al. 2005).
Land degradation in CRV of Ethiopia is frequently reported to be severe, and has been negatively affecting the ecosystem. The need for extra land for agriculture by farmers in the area is posing pressure on Acacia woodlands. Farmers are converting these woodlands to cultivated lands. Subsequently, these evolved cultivated lands are used to grow mainly a single crop for many years. Since feed shortage is so severe, due to the long drought season in the area, farmers almost totally remove the crop residues and feed their cattle or sell it to the nearby semi-urban small dairy farms, keeping the soil bare. This has negative impact on the soil organic matter thereby disrupting the aggregate stability of soil. It has been so common to see severe soil wind erosion in the area during the dry season. This study was therefore aimed at evaluating some soil properties effect on indicators for soil wind erosion in this rift valley. Soil aggregate stability significantly decreased following conversion of native Acacia woodland to conventional cultivated lands such as the TLCL and PAF. This could be associated with the loss of SOC under the respective land uses. In all land use types considered, animal free grazing caused trampling effect thereby increasing soil bulk density in the top 0–15 cm. In the study area, loss of soil moisture, lower porosity and higher bulk density were highly pronounced under TLCL and PAF than under MPL and PWL.
The authors would like to thank the Rural Capacity Building Project for funding the study. Laboratory technicians of the Zeway soil testing laboratory are also duly acknowledged for unreserved assistance during the soil sample preparation and analysis. Finally, the authors are also very grateful to the anonymous reviewers who forwarded their invaluable comments on the manuscript.
- Alberti G, Vedove GD, Zuliani M, Peressotti A, Simona CS, Giuseppe ZG (2010) Changes in CO2 emissions after crop conversion from continuous maize to alfalfa. Agric Ecosyst Environ 136:139–147Google Scholar
- Ashagrie Y, Zech W, Guggenberger G, Taye M (2007) Soil aggregation, and total and particulate organic matter following conversion of native forests to continuous cultivation in Ethiopia’. Soil Tillage Res 94:101–108View ArticleGoogle Scholar
- Bell LW, Kirkegaard JA, Swan A, Hunt JR, Huth NI, Fettell NA (2011) Impacts of soil damage by grazing livestock on crop productivity. Soil Tillage Res 113:19–29View ArticleGoogle Scholar
- Binkley D, Singer F, Kayea M, Rochellea R (2003) Influence of elk grazing on soil properties in Rocky Mountain National Park. For Ecol Manage 185:239–247View ArticleGoogle Scholar
- Biyensa (2011, Unpublished) Status of soil properties under different land use/land cover types in Adami Tulu, MSc thesis, Hawassa University, College of Agriculture, p 81.Google Scholar
- Børresen T (1999) The effect of straw management and reduced tillage on soil properties and crop yields of spring-sown cereals on two loam soils in Norway. Soil Tillage Res 51:91–102View ArticleGoogle Scholar
- Chaichi MR, Saravi MM, Malekian A (2005) Effects of livestock trampling on soil physical properties and vegetation cover (Case Study: Lar Rangeland, Iran). Int J Agric Biol 6:904–908Google Scholar
- Chepil WS (1952) Improved rotary sieve for measuring state and stability of Dry soil structure. Soil Sci Soc Am Proc 16:113–117View ArticleGoogle Scholar
- Curran-Cournane F, McDowell RW, Littlejohn R, Condron LM (2010) Effects of stock type on soil physical properties and losses of phosphorus and suspended sediment in surface runoff. In: 19th World Congress of Soil Science, Soil Solutions for a Changing World 1 – 6 August 2010, Brisbane, AustraliaGoogle Scholar
- De Souza ED, de Andrade G, Costa SEV, Anghinoni I, de Faccio CPC, de Oliveira EVF, Martins AP, Cao E, Andrighetti M (2010) Soil aggregation in a crop-livestock integration system under no-tillage. Revista Brasileira De Ciencia Do Solo 34:1365–1374View ArticleGoogle Scholar
- Díaz-Zorita M, Grove JH and Perfect E (2002) Aggregation, fragmentation, and structural Stability measurement. In: Lal R (ed) Encyclopedia of soil science. New York, p 37-40.Google Scholar
- Gajic B, Tapanarova A, Tomic Z, Kresovic B, Vujovic D, Pejic B (2013) Land use effects on aggregation and erodibility of Luvisols on undulating slopes. AJCS 7(8):1198–1204Google Scholar
- Getachew E, Ståhl G (1998) Functions for multi-phase assessment of biomass in acacia woodlands of the Rift Valley of Ethiopia. For Ecol Manage 105:79–90View ArticleGoogle Scholar
- Greeves GW, Leys JF, McTainsh GH (2007) Soil erodibility. In: Charman PEV, Murphy BW (eds) Soils – their properties and management. Oxford University Press, Melbourne, pp 206–221Google Scholar
- Hamza MA, Anderson WK (2005) Soil compaction in cropping systems. A review of the nature, causes and possible solutions. Soil Tillage Res 82:121–145View ArticleGoogle Scholar
- Hao X, Ball BC, Culley JLB, Carter MR, Parkin GW (2008) Soil density and porosity. In: Carter MR, Gregorich EG (eds) Soil sampling and methods of analysis. Taylor & Francis Group, LLC, U.S.A, pp 743–760Google Scholar
- Hartmann R (2008) Aggregation. In: Chesworth W (ed) Encyclopedia of soil science. Springer, The Netherlands, pp 30–33Google Scholar
- Itanna F (2005) Sulfur distribution in five Ethiopian Rift Valley soils under humid and semi- arid climate. J Arid Environ 62:597–612View ArticleGoogle Scholar
- Jansen H, Hengsdijk H, Dagnachew L, Ayenew T, Hellegers P, Splietoff P (2007) Land and water resources assessment in the Ethiopian CRV. In: Project: ecosystems for water, food and economic development in the Ethiopian CRV, Alterra rapport. Wageningen University, the NetherlandsGoogle Scholar
- Jiao Y, Whalen JK, Hendershot WH (2006) No-tillage and manure applications increase aggregation and improve nutrient retention in a sandy-loam soil. Geoderma 134:24–33View ArticleGoogle Scholar
- Lal R (2004) Carbon sequestration in dry land ecosystems. Environ Manage 33:528–544View ArticleGoogle Scholar
- Lal R, Shukla MK (2006) Principles of soil physics. Marcel Dekker, New YorkGoogle Scholar
- Liu X, Herbert SJ, Hashemi AM, Zhang X, Ding G (2006) Effects of agricultural management on soil organic matter and carbon transformation – a review. Plant Soil Environ 52(12):531–543Google Scholar
- Lyles L, Tatarko J (1988) Soil wind erodibility index in Seven North Central States. ASAE 31(5):1396–1399View ArticleGoogle Scholar
- Martínez LJ, Zinck JA (2004) Temporal variation of soil compaction and deterioration of soil quality in pasture areas of Colombian Amazonia. Soil Tillage Res 75:3–17View ArticleGoogle Scholar
- Masri Z, Ryan J (2006) Soil organic matter and related physical properties in a Mediterranean wheat-based rotation trial. Soil Tillage Res 87:146–154View ArticleGoogle Scholar
- Osunbitana JA, Oyedeleb DJ, Adekalu KO (2005) Tillage effects on bulk density, hydraulic conductivity and strength of a loamy sand soil in southwestern Nigeria. Soil Tillage Res 82:57–64View ArticleGoogle Scholar
- Proffitt AP, Bendotti S, Howell MR, Eastham J (1993) The effect of sheep trampling and grazing on soil physical properties and pasture growth for a red-brown earth. Aust J Agr Res 44:317–331View ArticleGoogle Scholar
- Proffitt APB, Bendotti S, McGarry D (1995) A comparison between continuous and controlled grazing on a red duplex soil. I. Effects on soil physical characteristics. Soil Tillage Res 35:199–210View ArticleGoogle Scholar
- Quirogaa AR, Buschiazzoa DE, Peinemann N (1999) Soil compaction is related to management practices in the semi-arid Argentine pampas. Soil Tillage Res 52:21–28View ArticleGoogle Scholar
- Radford BJ, Yule DF, Braunack M, Playford C (2008) Effects of grazing sorghum stubble on soil physical properties and subsequent crop performance. Am J Agric Biol Sci 3(4):734–742View ArticleGoogle Scholar
- Rouw A, Huon S, Soulileuth B, Jouquet P, Pierret A, Ribolzi O, Valentin C, Bourdon E, Chantharath B (2010) Possibilities of carbon and nitrogen sequestration under Conventional tillage and no-till cover crop farming (Mekong valley, Laos). Agric Ecosyst Environ 136:148–161View ArticleGoogle Scholar
- SAS Institute (2002) SAS/FSP 9 Procedures Guide. SAS Institute Inc, Cary, NC, USAGoogle Scholar
- Sharrow SH (2007) Soil compaction by grazing livestock in silvopastures as evidenced by changes in soil physical properties. Agroforestry Syst 71:215–223View ArticleGoogle Scholar
- Singh G, Jalota SK, Sidhu BS (2005) Soil physical and hydraulic properties in a rice-wheat cropping system in India: effects of rice-straw management. Soil Use Manage 21:17–21View ArticleGoogle Scholar
- Siri-Prieto G, Reeves DW, Raper RL (2007) Tillage systems for a cotton-peanut rotation with winter-annual grazing: impacts on soil carbon, nitrogen and physical properties. Soil Tillage Res 96:260–268View ArticleGoogle Scholar
- Snyder CS, Bruulsema TW, Jensen TL, Fixen PE (2009) Review of greenhouse gas emissions from crop production systems and fertilizer management effects. Agric Ecosyst Environ 133:247–266View ArticleGoogle Scholar
- Wilson GWT, Rice CW, Rilling MC, Springer A, Hartnett DC (2009) Soil aggregation and carbon sequestration are tightly correlated with the abundance of arbuscular mycorrhizal fungi. Ecol Lett 12:452–461View ArticleGoogle Scholar
- Woodruff NP, Siddoway FH (1965) A wind erosion equation. Soil Sci Soc Am Proc 29:602–608View ArticleGoogle Scholar
- Yang S, Lianyou L, Ping Y, Tong C (2007) A review of soil erodibility in water and wind erosion research. J Geogr Sci 15(2):167–176Google Scholar
- Yimer F and Abdelkadir A (2010) Soil property changes following conversion of Acacia woodland into grazing and farmlands in the rift valley area of Ethiopia. Land Degradation Dev. doi:https://doi.org/10.1002/ldr.1022.
- Zeleke TB, Grevers MCG, Si BC, Mermuta AR, Beyene S (2004) Effect of residue incorporation on physical properties of the surface soil in the South CRV of Ethiopia. Soil Tillage Res 77:35–46View ArticleGoogle Scholar
- Zewdie E (2004) Characterization and genesis of some soils of the Ethiopian Rift Valley Showing andic properties. Ethiop J Nat Resour 6:215–235Google Scholar
This is an Open Access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly credited.
